Rough Transmission Polyurethane Round Belt For Packing machine

Çin Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikalar
Çin Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikalar
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

Ben sohbet şimdi

Rough Transmission Polyurethane Round Belt For Packing machine

Rough Transmission Polyurethane Round Belt For Packing machine
Rough Transmission Polyurethane Round Belt For Packing machine Rough Transmission Polyurethane Round Belt For Packing machine Rough Transmission Polyurethane Round Belt For Packing machine Rough Transmission Polyurethane Round Belt For Packing machine

Büyük resim :  Rough Transmission Polyurethane Round Belt For Packing machine

Ürün ayrıntıları:
Place of Origin: China
Marka adı: jiuna
Sertifika: ROHS
Model Number: Diameter 2mm~20mm
Ödeme & teslimat koşulları:
Minimum Order Quantity: 10rolls
Packaging Details: Inner packing is plastic film .outer packing is carton .
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability: 96.000 meters per Month
Detaylı ürün tanımı
color: green orange material: PU
longth: 300m/roll 200m/roll 100m/roll 30m/roll hardness: 85A-90A
tensile rate: 0.3kg-31.3kg type: round belt
Vurgulamak:

PU yuvarlak kayış

,

yeşil yuvarlak kemer

Rough Transmission Polyurethane Round Belt For Packing machine
Detailed Product Description:
PU Cord Belt Application :
1. Wall floor tile conveying industrial line
2. printing and packing machine
3. food & beverage processing
4. wood processing
5. paper processing
6. electronic
7. post service
8. tobacco transmission line
PU Cord Properties :
-Excellent abrasion resistance.
-Good resistance to fuel , oils and oxygen.
-Contains no plasticizer.
-Wide application temperature from -30℃~+80℃
1.24 hours technical support by email
2.Professional After-sales service
3. ISO9001:2000 and TS16949 certificated.
4. OEM available.
5. More than ten years of sales and manufacture experience
6.100% test for air pressure and inspection for product appearance before shipment.
7. Long lifespan, competitive price.
8. Good payment term.
9. Fast delivery.
10.Thread Standard: BSPP, BSPT, NPT, METRIC etc. Our products are exported to more than
 30 countries in the whole world.
11. Our products are showed at international fair, such as Germany, Italy, America, Brazil,
Dubai,
Russia, Shanghai China fair etc each year.
12. Location advantage: Nearby Ningbo port, the second largest port in China, convenient
transportation and low cost, and close to Shanghai, convenient for customers to visit
our factory


Items No. φleast radius of gyrationstretch rateMaximum tensile rateHardnesslength of rolled

DIA
(mm)

InmmStretching rateKgLbs

Hardness
(A)

Roll
(m)

20.79 201.5-3%0.30.790400
30.98251.5-3%0.71.690400
41.38351.5-3%1.22.785200
51.57401.5-3%2.04.385100
61.97501.5-3%3.27.085100
72.17551.5-3%4.19.085100
82.56651.5-3%5.011.085100
92.95751.5-3%6.815.08550
102.95751.5-3%7.717.08550
123.941001.5-3%12.227.08530
154.721201.5-3%17.739.08530
185.711451.5-3%25.456.08530
206.301601.5-3%31.369.085

30




Rough Transmission Polyurethane Round Belt For Packing machine 0Rough Transmission Polyurethane Round Belt For Packing machine 1Rough Transmission Polyurethane Round Belt For Packing machine 2
