8mm Oil-Resistant PU Conveyor Belt with Diameter 2-20mm for Drive Transmission

  • 8mm Oil-Resistant PU Conveyor Belt with Diameter 2-20mm for Drive Transmission
Min sipariş miktarı 1.000
Fiyat 0.5

Ücretsiz numune ve kuponlar için bana ulaşın.

Naber:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Herhangi bir endişeniz varsa, 24 saat çevrimiçi yardım sağlıyoruz.

x
Ürün ayrıntıları
Model No. Dia 2mm-20mm Tip PU Yuvarlak Kemer
Malzeme pu Malzemenin İçinde pu
Yüzey Yumuşak ya da Kaba Gerilme mukavemeti 55N/mm2
Çap 2 ~ 20 mm Sertlik Kıyı (A) 85 ~ 90
germe oranı %1,5-3 Maksimum gerilme oranı Kg (çapa göre değişir)
En az yarıçap İn (çapa göre değişir) Rulo uzunluğu Rulo (M) (çapa göre değişir)
Özellik Yağa dirençli, asit ve alkali dirençli, gözyaşına dayanıklı, ısıya dayanıklı, soğuğa dayanıklı, aşın Aşınma direnci Üstün
Darbe direnci Yüksek
Vurgulamak

8mm PU Conveyor Belt

,

Oil-Resistant PU Conveyor Belt

,

Diameter 2-20mm PU Conveyor Belt
Mesaj bırakın
Ürün Açıklaması
8mm PU Conveyor Belt for Driving

Our high-performance Polyurethane (PU) round belts are designed for transmission applications in industrial machinery and product conveyance systems. These belts are ideal for transporting various materials including glass, tile, and other industrial products.

Key Features:
  • Outstanding abrasion resistance
  • High tensile and tear strength
  • Resistance to oils, fuels, and oxygen
  • Excellent weatherability and impact resistance
  • Low compression set
  • Available with smooth or rough surfaces
  • Reinforced with polyester, nylon, or fibers
  • Can be welded into O-rings
Applications:
  • Newspaper conveying systems
  • Packing machines
  • Ceramic and stoneware processing plants
  • Floor and roof tiles conveying
  • Wood working machinery
  • Textile machines
  • Paper industry machines
  • Food grading and processing machines
Technical Specifications:
Items NO. Φ Least Radius of Gyration Stretching Rate Maximum Tensile Rate Hardness Length of Roll
DIA(mm) In mm % Kg Lbs Shore(A) Roll(m)
2mm 0.79 20 1.5-3% 0.3 0.7 95 400
2.5mm 0.87 22 1.5-3% 0.4 0.9 95 400
3mm 0.98 25 1.5-3% 0.7 1.6 90 400
3.5mm 1.18 30 1.5-3% 0.95 2.1 90 400
4mm 1.38 35 1.5-3% 1.2 2.7 90 200
5mm 1.57 40 1.5-3% 2 4.3 90 100
6mm 1.97 50 1.5-3% 3.2 7 90 100
7mm 2.17 55 1.5-3% 4.1 9 90 100
8mm 2.56 65 1.5-3% 5 11 90 100
9mm 2.95 75 1.5-3% 6.8 15 90 50
10mm 3.94 100 1.5-3% 7.7 17 90 50
12mm 3.94 100 1.5-3% 12.2 27 90 30
15mm 4.72 120 1.5-3% 17.7 39 90 30
18mm 5.71 145 1.5-3% 25.4 56 90 30
20mm 6.3 160 1.5-3% 31.3 69 90 30
