High Strength Polyurethane V Belt with Diameter 2 ~20 mm and ISO9001: 2008 Certification for Drive Transmission

  • High Strength Polyurethane V Belt with Diameter 2 ~20 mm and ISO9001: 2008 Certification for Drive Transmission
Min sipariş miktarı 1.000
Fiyat 0.5

Ücretsiz numune ve kuponlar için bana ulaşın.

Naber:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Herhangi bir endişeniz varsa, 24 saat çevrimiçi yardım sağlıyoruz.

x
Ürün ayrıntıları
Model No. Dia 2mm-20mm Tip PU Yuvarlak Kemer
Malzeme pu Malzemenin İçinde pu
Yüzey Yumuşak ya da Kaba Gerilme mukavemeti 55N/mm2
Çap 2 ~ 20 mm Sertlik 85 a ~ 90 a
germe oranı %1,5-3 Maksimum gerilme oranı Kg (çapa göre değişir)
Rulo uzunluğu Rulo (M) (çapa göre değişir) En az yarıçap İn (çapa göre değişir)
Özellik Yağa dirençli, asit ve alkali dirençli, gözyaşına dayanıklı, ısıya dayanıklı, soğuğa dayanıklı, aşın Aşınma direnci Üstün
Darbe direnci Yüksek
Vurgulamak

High Strength Polyurethane V Belt

,

Diameter 2 ~20 mm PU Round Belt

,

ISO9001: 2008 Certified Transmission Belt
Mesaj bırakın
Ürün Açıklaması
High Strength PU Belt Transmission Supplier

We provide a comprehensive range of Polyester and Polyurethane Round belts designed for industrial transmission machines and product conveyance applications. Our belts are suitable for transporting various materials including glass, tiles, and other industrial products.

Product Features
  • Outstanding abrasion resistance
  • High tensile and tear strength
  • Resistance to oils, fuels, and oxygen
  • Excellent weatherability and high impact resistance
  • Low compression set
  • Available with smooth or rough surfaces
  • Reinforced with polyester, nylon, or fibers
  • Can be welded to form O-rings
  • Supplied with connecting tools and accessories
Applications

Our PU belts are widely used in:

  • Newspaper conveying systems
  • Packing machines
  • Ceramic and stoneware processing plants
  • Floor and roof tiles conveying
  • Wood working machinery
  • Textile machines
  • Paper industry machines
  • Food grading and processing machines
Technical Specifications
Items NO. Φ Least radius of gyration Stretching rate Maximum tensile rate Hardness Length of rolled
DIA(mm) In mm % Kg Lbs Shore(A) Roll(m)
2mm 0.79 20 1.5-3% 0.3 0.7 95 400
2.5mm 0.87 22 1.5-3% 0.4 0.9 95 400
3mm 0.98 25 1.5-3% 0.7 1.6 90 400
3.5mm 1.18 30 1.5-3% 0.95 2.1 90 400
4mm 1.38 35 1.5-3% 1.2 2.7 90 200
5mm 1.57 40 1.5-3% 2 4.3 90 100
6mm 1.97 50 1.5-3% 3.2 7 90 100
7mm 2.17 55 1.5-3% 4.1 9 90 100
8mm 2.56 65 1.5-3% 5 11 90 100
9mm 2.95 75 1.5-3% 6.8 15 90 50
10mm 3.94 100 1.5-3% 7.7 17 90 50
12mm 3.94 100 1.5-3% 12.2 27 90 30
15mm 4.72 120 1.5-3% 17.7 39 90 30
18mm 5.71 145 1.5-3% 25.4 56 90 30
20mm 6.3 160 1.5-3% 31.3 69 90 30
