85A Hardness Polyurethane V Belt with A, B, C, D, M, Z Specification for Drive Transmission in -35 to 80 Temperature Range
| Min sipariş miktarı | 1.000 |
|---|---|
| Fiyat | 1 |
Ücretsiz numune ve kuponlar için bana ulaşın.
Naber:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
Herhangi bir endişeniz varsa, 24 saat çevrimiçi yardım sağlıyoruz.
xÜrün ayrıntıları
| Malzeme | pu | Malzemenin İçinde | pu |
|---|---|---|---|
| Sertlik | 85a | Sıcaklık aralığı | -35 - 80 |
| Kıyı Bir Sertlik | 80A - 98a | Yuvarlak kemer çapı. | 2 mm ila 30 mm |
| V -keyt tipi | A, B, C, D, M, Z | Bir Tip X | 13 mm |
| Bir H Tipi | 8mm | B Tip X | 17 mm |
| B Tip H | 11 mm | C Tip X | 22mm |
| C Tip H | 14 mm | D Tip X | 32 mm |
| D Tip H | 19 mm | ||
| Vurgulamak | 85A Hardness Polyurethane V Belt,A,B,C,D,M,Z Specification PU V Belt,Temperature Range -35 - 80 TPU V Belt |
||
Ürün Açıklaması
Urethane Transmission Red Polyurethane V Belt Supplier
Alkali Resistant Smooth 80A Polyurethane V Belt For Conveyor
TPU V Belts Specifications
High-performance PU V belt with excellent durability and resistance properties.
- Thermoplastic polyurethane material, easy to be melted jointed
- Reinforced by Polyester Cord or Steel Cord
- Temperature range: -35°C to 80°C
- Shore A hardness range: 80A - 98A
- Excellent resistance to flex, abrasion resistance, and easy jointing
- Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics industries
- Specialized applications in ceramic industry for glaze lines, polishing lines, and transmission lines
Round Belt Specifications
Available in diameters from 2mm to 30mm. Options include:
- Smooth Belt with good surface finish
- Rough belt with even surface roughness
V-belt Specifications
Available in A, B, C, D, M, Z types with excellent wear resistance, particularly suited for ceramic industry applications.
| Specification | X(mm) | H(mm) | Hardness (Shore A) | M/rolls | Reinforced |
|---|---|---|---|---|---|
| A | 13mm | 8 | 90A | 30 | • |
| B | 17mm | 11 | 90A | 30 | • |
| C | 22mm | 14 | 90A | 30 | • |
| D | 32mm | 19 | 90A | 30 | • |
| M | 8mm | 4 | 90A | 50 | |
| Z | 10mm | 5 | 90A | 50 |
