Wuxi Jiunai Polyurethane Products Co., Ltd
Ana sayfa ÜrünlerPoliüretan Yuvarlak Kemer

Diameter 6mm Round Polyurethane Belts Ceramic Machine Transmission

Çin Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikalar
Çin Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikalar
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

Ben sohbet şimdi

Diameter 6mm Round Polyurethane Belts Ceramic Machine Transmission

Diameter 6mm Round Polyurethane Belts Ceramic Machine Transmission
Diameter 6mm Round Polyurethane Belts Ceramic Machine Transmission Diameter 6mm Round Polyurethane Belts Ceramic Machine Transmission Diameter 6mm Round Polyurethane Belts Ceramic Machine Transmission Diameter 6mm Round Polyurethane Belts Ceramic Machine Transmission

Büyük resim :  Diameter 6mm Round Polyurethane Belts Ceramic Machine Transmission

Ürün ayrıntıları:
Place of Origin: China
Marka adı: Jiuna
Sertifika: ROHS
Model Number: Diameter 6 mm
Ödeme & teslimat koşulları:
Minimum Order Quantity: 10rolls
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment
Supply Ability: 95.000 meters per Month
Detaylı ürün tanımı
length: 200m/roll color: orange
type: Pu smooth round belt Appl.Temp: -35/+75
Tensile Strength: 55N/mm2 Main function: Drive transmission
Vurgulamak:

PU yuvarlak kayış

,

PU haddelenmiş kemer

Diameter 6mm Round Polyurethane Belts Ceramic Machine Transmission

Details:
(1)Thermoplastic polyurethane material, easy to be melted jointed
(2)Reinforced by Polyester Cord or Steel Cord
(3)Temperature range -35°C - 80°C
(4)Shore A hardness range 80A - 98A
(5)With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics.
 Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics
 and other industries, especially in the ceramic industry, widely used in the facilities line the
glaze, polishing lines, and transmission line.
(6)Round Belt:
Round Belt Dia. is from 2mm to 30mm
Smooth Belt with good surface finish; Rough belt with even surface roughness. They are
 used widely.
PU Round belt with reinforcement

polyurethane round belt of  introduction:

We offer a complete line of Polyester and Polyurethane Round belts for use in industrial machines. And In the conveyance of products ranging from transport machine,conveyor machine to glass and tile. Round belts are available with smooth and rough surfaces and reinforced with polyester, nylon or fibers. Also can welding belt to O-ring . supply the connecting tools & Accessories for polyurethane belts , include clamp ,the Electric Iron and Knife , Connecting methods is hotpress welding , overlap welding .
The very elastic and flexible material PU 85 A ~90 A is particularly suitable for lead in conveyors and vertical shafts .



Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30


Service commitment:
“Quality for keeping going ,Credit to win the world”

Diameter 6mm Round Polyurethane Belts Ceramic Machine Transmission 0
