Abrasion Resistant polyurethane belt Textile And Glass 400 M / Roll

Çin Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikalar
Çin Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikalar
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

Ben sohbet şimdi

Abrasion Resistant polyurethane belt Textile And Glass 400 M / Roll

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt

Büyük resim :  Abrasion Resistant polyurethane belt Textile And Glass 400 M / Roll

Ürün ayrıntıları:
Place of Origin: china
Marka adı: jiuna
Sertifika: ROHS
Model Number: Diameter2mm-20mm
Ödeme & teslimat koşulları:
Minimum Order Quantity: 10 rolls
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: L/C, T/T, L/C, Western Union, MoneyGram
Supply Ability: 100,000,00 as per month
Detaylı ürün tanımı
color: orange color hardness: 90A
longth: 400 m/roll Usage: Transmission Chain
type: PU rough round belt surface: smooth
material: PU
Vurgulamak:

pu yuvarlak kemer

,

yeşil yuvarlak kemer

,

poliüretan yuvarlak kemer 400m/rulo

Abrasion Resistant polyurethane belt Textile And Glass 400 M / Roll



Smooth Surface Urethane Round Belting Rohs Approved , Low Compression

Widely used in textiy

  printing and packing machine,food & beverage processing, wood processing  ,  paper processing electronic post service tobacco transmission line
 Wall floor tile conveying industrial line

Ceramic industry line or polishing line

We supply different kinds of PU V-belt, Round belt, Surper grip belt & Pentagon

Color: Orange, Red, Dark Green, Ivory, Natural  .

  • Shore Hardness:  Round belt - 87°A ± 2 .
  • Rough surface: Normal Rough / More Rough  .
  • Steel, Glass & Aramid Reinforcement on request.
  • Easily jointed with BCTech's Welding Kits
  • Features:
  • High tensile and tear strength
  • High abrasion resistance
  • Resistant to oil, grease, dust, moisture & most chemicals
  • Temperature Range: -35 ~ 85 Degrees

The types of TPU V-Belt:

Glossy surface round belt, rough surface round belt, v-belt, pentaone belt, hexagonal belt,

heptagonal belt, supper-grip belt, T belt, perallel belt.

Applications:
Mainly used in transmission and distribution products for the textile, clothing, food, packaging, printing, machinery, electronic, glass, chemicals, automobiles, beverages, furniture, toys, paper and other industries; Especially in the ceramic industry, widely used in the glazing Lines, transmission lines, polishing line etc.
Normal specifications including Z, M, A, B, C, D and the Pentangular Belt including A, B, C type, pentagonal belt normally used in the production line's corner.



Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile   rate

Hardness

Length of rolled

DIA(mm)

 In

mm

    %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30



Abrasion Resistant polyurethane belt Textile And Glass 400 M / Roll 0

Abrasion Resistant polyurethane belt Textile And Glass 400 M / Roll 1

Service commitment:



“ Quality for keeping going ,Credit to win the world”
