Heat Resistant Polyurethane Rubber Round Belt Extruded Thermo

Çin Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikalar
Çin Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikalar
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

Ben sohbet şimdi

Heat Resistant Polyurethane Rubber Round Belt Extruded Thermo

Heat Resistant Polyurethane Rubber Round Belt Extruded Thermo
Heat Resistant Polyurethane Rubber Round Belt Extruded Thermo Heat Resistant Polyurethane Rubber Round Belt Extruded Thermo Heat Resistant Polyurethane Rubber Round Belt Extruded Thermo Heat Resistant Polyurethane Rubber Round Belt Extruded Thermo

Büyük resim :  Heat Resistant Polyurethane Rubber Round Belt Extruded Thermo

Ürün ayrıntıları:
Place of Origin: china
Marka adı: jiuna
Sertifika: ROHS
Model Number: dia 2-20mm
Ödeme & teslimat koşulları:
Minimum Order Quantity: 10rolls
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment
Supply Ability: 6000 piece per Month
Detaylı ürün tanımı
color: green or orange hardness: 85A-90A
export port: shanghai length: as your request
Tensile Strength: 55N/mm2 material: PU
Vurgulamak:

PU haddelenmiş kemer

,

yeşil yuvarlak kemer

Heat Resistant Polyurethane Rubber Round Belt Extruded Thermo

Features:

Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set



Application:

Newspaper conveying,
Packing machines,
Ceramic and stoneware processing plants,
Floor and roof tiles conveying,
Wood Working machineries,
Textile machines,
Paper industry machines,
Food grading machines, other food processing machines.



Products introduction:

We offer a complete line of Polyester and Polyurethane Round belts for use in industrial machines. And In the conveyance of products ranging from transport machine, convey or machine to glass and tile. Round belts are available with smooth and rough surfaces and reinforced with polyester, nylon or fibers. Also can welding belt to O-ring . supply the connecting tools & Accessories for polyurethane belts , include clamp ,the Electric Iron and Knife , Connecting methods is hot press welding , overlap welding .

The very elastic and flexible material PU 85 A ~90 A is particularly suitable for lead in conveyors and vertical shaft.



Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30





Heat Resistant Polyurethane Rubber Round Belt Extruded Thermo 0Heat Resistant Polyurethane Rubber Round Belt Extruded Thermo 1
