Wuxi Jiunai Polyurethane Products Co., Ltd
Ana sayfa ÜrünlerPoliüretan Yuvarlak Kemer

Wide Application Temperature Transmission Urethane Belt For Machine

Çin Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikalar
Çin Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikalar
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

Ben sohbet şimdi

Wide Application Temperature Transmission Urethane Belt For Machine

Wide Application Temperature Transmission Urethane Belt For Machine
Wide Application Temperature Transmission Urethane Belt For Machine Wide Application Temperature Transmission Urethane Belt For Machine Wide Application Temperature Transmission Urethane Belt For Machine Wide Application Temperature Transmission Urethane Belt For Machine

Büyük resim :  Wide Application Temperature Transmission Urethane Belt For Machine

Ürün ayrıntıları:
Place of Origin: china
Marka adı: jiuna
Sertifika: ROHS
Model Number: Diameter 2mm-20mm
Ödeme & teslimat koşulları:
Minimum Order Quantity: 10 rolls
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100.000 meters per Month
Detaylı ürün tanımı
hardness: 85A renk: Yeşil
germe oranı: %1,5-3 çekme oranı: 0,7 lbs-69 lbs
malzeme: PU uzunluk: 400m/rulo 300m/rulo 200m/rulo 100m/rulo 30m/rulo
GTİP Kodu: 39269010 Üretim kapasitesi: Uzun Vadeli Tedarik
Vurgulamak:

pu yuvarlak kemer

,

pu ekstrüde kemer

,

12mm çaplı poliüretan yuvarlak kemer



Wide Application Temperature Transmission Urethane Belt For Machine





Detailed Product Description



Industrial 12mm Polyurethane Round Belt Orange or Green for Packing Machine



Details:
(1)Thermoplastic polyurethane material, easy to be melted jointed
(2)Reinforced by Polyester Cord or Steel Cord
(3)Temperature range -35°C - 80°C
(4)Shore A hardness range 80A - 98A
(5)With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.
(6)Round Belt:
Round Belt Dia. is from 2mm to20mm
Smooth Belt with good surface finish; Rough belt with even surface roughness. They are used widely.
PU Round belt with reinforcement



polyurethane Round Belts Feature:



         1.       With excellent bend resistant

         2.       abrasion/wear resistant

         3.       easily connected

         4.       it's not easy to be broken at low temperature

         5.       fuel and oil resistant

         6.       anti static





polyurethane round belt Application :



                                     1.       Widely used in textile

                                     2.       printing and packing machine

                                     3.       food & beverage processing

                                     4.       wood processing

                                     5.       paper processing

                                     6.       electronic

                                     7.       post service

                                     8.       tobacco transmission line

                                     9.       Wall floor tile conveying industrial line

                                    10.      Ceramic industry line or polishing line







Items No. φ least radius of gyration stretch rate Maximum tensile rate Hardness length of rolled

Dia.

(mm)

In mm Stretching rate Kg Lbs

Hardness

(A)

Roll

(m)

2mm 0.79 20 1.5-3% 0.3 0.7 90 A 400
3mm 0.98 25 1.5-3% 0.7 1.6 90 A 400
4mm 1.38 35 1.5-3% 1.2 2.7 85 A  200
15mm 4.72 120 1.5-3% 17.7 39.0 85 A  30
18mm 5.71 145 1.5-3% 25.4 56.0 85 A  30
20mm 6.30 160 1.5-3% 31.3 69.0 85 A  30





Products introduction:





Urethane round belts are elastomeric belts for power transmission application.

Having most metric sizes (2mm to 20mm) and standard O-ring sizes.

Polyether and Polyurethane round belts have best resilience of any elastic material.

Polyester product has good wear resistance, its wear resistance is 3.5 times

of common plastic and rubber.





Service commitment:

“Quality for keeping going ,Credit to win the world”



Wide Application Temperature Transmission Urethane Belt For Machine 0Wide Application Temperature Transmission Urethane Belt For Machine 1Wide Application Temperature Transmission Urethane Belt For Machine 2



Wide Application Temperature Transmission Urethane Belt For Machine 3
